Heavy Metal Analysis

Analysis of regulated toxic elements at ultra‑trace level for food, feed and water compliance.

Green grass field texture background.

From Environmental Entry to Regulatory Control

Water droplet falling onto soil with a small plant in the background.

Heavy metals originate from natural and anthropogenic sources and occur in food and water matrices at trace and ultra‑trace levels. Uptake via soil, water and air leads to accumulation along the food chain, requiring analytical control at legally defined limits.

Toxicological relevance depends on both element and chemical form. Inorganic arsenic is carcinogenic, whereas organic arsenic species in fish are considered non‑toxic. Methylmercury biomagnifies in aquatic food chains, while cadmium accumulates in human tissue over long time periods. This requires element‑specific analysis and, where mandated, speciation to distinguish toxic from non‑toxic forms.

Parameter Portfolio

Comprehensive portfolio of elemental analysis, supporting regulatory compliance and continuous monitoring.

Toxic Elements

Covers toxic elements regulated under Regulation (EU) 2023/915 as well as additional elements subject to guidance values and ongoing regulatory monitoring. Includes total element determination and, where required, speciation based on toxicological relevance.

Methods: ICP‑MS, AAS

Common analytes: Lead (Pb), Cadmium (Cd), Mercury (total, methylmercury), Arsenic (total, inorganic), Nickel (Ni), Tin (inorganic Sn), Aluminium (Al), Antimony (Sb), Chromium (total, Cr(VI)), Barium (Ba)

Analytical Methods

Method selection is driven by element, required detection limit, specification need and matrix.
ICP‑MS is the default platform, supported by dedicated techniques.
Default Method

ICP‑MS – Multi‑Element Analysis

Simultaneous determination of multiple toxic elements following microwave‑assisted acid digestion. Provides ultra‑trace sensitivity and broad matrix applicability for routine regulatory control.

Suitable for: Lead, cadmium, total arsenic, nickel, tin, aluminium, antimony, chromium, carium, food, feed, water, food contact materials

Confirmatory Analysis

Graphite Furnace AAS

Single‑element technique with high matrix tolerance. Used as confirmatory or independent second method where required.

Suitable for: Lead, cadmium, chromium, nickel

Analytical Interpretation

Heavy metal results are evaluated in the context of matrix, element and applicable legislation.
Chemist testing raw material identification with an FTIR spectrometer in a quality control laboratory.

Maximum Level Compliance

Regulatory verification of heavy metal concentrations against legally binding EU maximum levels.

Typical applications: Official food control, market surveillance, compliance verification

Close-up of different types of rice.

Arsenic Speciation in Rice

Total arsenic is insufficient for regulatory assessment. Compliance is based on inorganic arsenic determined by ICP‑MS to distinguish toxic forms from non‑toxic species.

Typical applications: Rice & rice products, baby food, import control

Fresh fish and seafood displayed on ice at a market.

Mercury in Fish & Seafood

Evaluation of mercury exposure in aquatic food chains. Separate regulatory limits apply for total mercury and methylmercury in predatory fish and seafood.

Typical applications: Tuna, swordfish, shark, seafood, canned products

Chocolate bar with cocoa beans.

Cadmium in Cocoa Products

Cadmium levels depend on origin and cocoa solid content. Interpretation follows category‑specific EU maximum levels for chocolate and cocoa‑derived products.

Typical applications: Chocolate, cocoa powder, raw material sourcing decisions

Shower head with running water in blue bathroom.

Drinking Water & Process Water

Assessment of heavy metal parameters according to national transpositions. Accredited sampling available.

Typical applications: Drinking water compliance , process water monitoring, infrastructure control

Two scientists conducting food research with a laptop in a laboratory.

Supply Chain & Incoming Goods Control

Risk‑based screening of raw materials prior to processing to prevent downstream non‑compliance.

Typical applications: Spices, cocoa, rice, fish, algae, supplier verification (HACCP, IFS, BRC)

Illustration Law

Regulatory Framework

Regulated under Regulation (EU) 2023/915 defining legally binding maximum levels for toxic elements in food and water. Matrix‑ and element‑specific limits determine result interpretation.

UK market: EU‑derived requirements apply under UK retained EU law (Great Britain). Matrix‑ and element‑specific limits are assessed against the applicable UK legislation.
